Dell Optiplex 7020, 14th generation CI5, 8gb, 512 SSD

Dell OptiPlex 7020 – Intel Core i5‑14500 (14th Gen), 8 GB, 512 GB SSD

🧠 Processor & Chipset

• Intel Core i5‑14500 (14th Gen)

  • 14 cores / 20 threads

  • Base clock ~2.6 GHz, Turbo boost up to ~5.0 GHz

  • Approx. 24 MB Smart Cache

• Based on Intel Q670 chipset

💾 Memory

• 8 GB DDR5 RAM (single-channel; 1 × 8 GB)

• Standard speed: ~4800 MT/s

• Two DIMM slots; expandable up to ~64 GB

💽 Storage

• 512 GB PCIe NVMe SSD (M.2 2230/2280, Gen 4, Class 35)

🎨 Graphics

• Integrated Intel UHD Graphics 770

🌐 Networking

• Gigabit Ethernet (RJ‑45)

• Wi‑Fi 6E including Bluetooth (integrated in many models via Intel AX210 combo module)

🔊 Audio

• High-Definition audio subsystem with internal speaker

🔌 Ports & Connectivity

Front Panel:

• 1× USB 3.2 Gen 2×2 Type‑C (up to 20 Gbps)

• 1× USB 3.2 Gen 2 Type‑A (10 Gbps)

• 2× USB 2.0

• Universal 3.5 mm audio jack (headset/mic)

Rear Panel:

• 1× USB 3.2 Gen 2 Type‑A (10 Gbps)

• 3× USB 3.2 Gen 1 (5 Gbps)

• 2× USB 2.0 (with SmartPower On)

• HDMI 1.4b

• DisplayPort 1.4a (often multiple)

• RJ‑45 Gigabit Ethernet

• Retasking line‑out / line‑in audio

• Optionally: VGA and serial ports (configuration-dependent)

🧩 Expansion Slots & Bays

• Up to 3 SATA 3.0 for 2.5″/3.5″ drives or slim optical drive

• M.2 slots:

  • 2230 for Wi‑Fi/Bluetooth

  • 2230/2280 for SSD

• PCIe slots (full-height):

  • 1× PCIe Gen 4 x16

  • 1× PCIe Gen 3 x4 (full‑height)

  • 1× PCIe Gen 3 x1

  • 1× legacy PCI (on some configurations)

⚡ Power Supply

• 180 W 80 PLUS Bronze PSU (typical for SFF models)

• Tower models may offer 260 W Bronze or even 500 W Platinum PSU options

📦 Physical Dimensions & Form Factor

• Available in Small Form Factor (SFF) and Mini-Tower / Micro Plus chassis

• SFF dimensions: approximately 92.6 × 292.8 × 290 mm (WxDxH), weight ~4–5 kg

• Tower dimensions: ~367 × 169 × 300.8 mm, weight ~6–9 kg depending on configuration

🧰 Included Extras

• Dell wired keyboard (KB216) and wired optical mouse (MS116)

• Optional DVD±RW optical drive (in many Tower/SFF packages)

💻 Preinstalled Software

• Freedos in DOS-only variants

• Some configs may ship with Windows 11 Pro

🛡️ Warranty

•  1-year limited hardware warranty included on business-model configurations
